Name: | Fisco Lab Reactor |
---|---|
Power supply | 380V/50Hz |
Metal for contact material | SS316L |
Control mode | PLC |
Operating medium | Touch screen |
Emulsifying tank | |
Maximum allowable emulsifying capacity | 10L |
Minimum allowable emulsifying capacity | 5L |
Minimum allowable mixing capacity | 5L |
Maximum operating temperature | 95℃ |
Vacuum value | 0.09Mpa |
Maximum working viscosity | <200000cp |
Mixing power | 0.25KW |
Range of agitation speed | 0~85rpm/min |
Impeller form | Four—bladed propeller |
Scraper material | PTFE |
Homogenizer type | Homogenizer bottom |
Homogenizer Power | 2.2kW |
Homogenizer speed range | 1000~3600rpm |
Agitator type | Suitable for high viscosity work head |
Temperature test | Yes |
Sight glass | Yes |
Sight lamp | Yes |
Feed way | Vacuum suction and manual feed |
Lifting way | Electric lifting |
Liquid tank | |
Capacity | 5L |
Mixer power | 0.18kW |
Mixer speed range | 0~1500rpm |
Allowable ambient temperature | 5~40℃ |
Allowable relative humidity | 80% |
Full size | 1200x900x1500mm |
Weight | ~700kg |
Various reaction systems can be customized according to the user's process flow and product characteristics.
It has many advantages: PLC control, high-efficiency mixing, high-speed dispersion, emulsification and homogenization, multiple feeding modes, and vacuum or pressure environment for customers to simulate real-life conditions or small-scale production.
BIOLOGY & PHARMACY
Veterinary Vaccines
Pharmaceutical Ointment
Hyaluronic Acid
FOOD
Milk
Soft Drink
DAILY CARE
Skin Care Products
Personal Care Products
Cosmetics
CHEMICAL INDUSTRY
New Energy
Pesticide
TDI
Spandex
NEW MATERIAL
Polymer Material
